About AUTOM Series™ - Compact Low Energy Swing Door Operators
The SDC AutoMINI™ low-energy swing door operator delivers the same advanced performance and features of the standard AUTO series in a compact 23” housing, engineered specifically to simplify installation and improve field efficiency.
Built on SDC’s proven AUTO platform, the AutoMINI incorporates installer-focused enhancements such as slotted mounting keyholes and a fully reversible housing design. These features reduce installation time, simplify on-site work, and optimize storage and handling efficiency in trucks and warehouses.
SDC's operator is built with a state-of-the-art microprocessor-based unit that is self-tuning and self-learning while offering nonhanded operation, full-mechanical stops, and a variety of interface options for sensors, push-plates, fire alarms and electrified locks.
SDC's operator is belt driven with a combination of gears and pulleys which requires less torque, less power, absorbs more abuse, and is quieter than other automatic door openers while complying with all US and Canadian ADA requirements. Onboard diagnostics simplifies troubleshooting for ease of installation and all SDC operators can be easily configured for surface mounted push/pull applications. ANSI certified not required for initial installation.
Every operator should be ordered with an AUTO-IR presence sensor to mitigate liability.
x See Datasheet For More InfoBenefits for AUTOM Series™ - Compact Low Energy Swing Door Operators
Disability Solutions
Leaders in Latch RetractionCertifications for AUTOM Series™ - Compact Low Energy Swing Door Operators
- Meets ANSI A156.19 Power Assist and Low Energy Power Operated Doors
- UL325 Door, Drapery, Gate, Louver, Window Operators and Systems or Use on Fire and Smoke Check Doors
- ETL Intertek Tested to UL/cUL Standards for Automatic Doors Used on Fire and Smoke Barrier Doors and CSA C22.2 No. 247-92 for Operators and Systems of Doors
- ADA Americans With Disabilities Act
- FCC47CFR Part 15 Class B Emissions Requirements (USA)
- NFPA101 Life Safety Code
- UL10C Fire-Rated, 3hr
- ETL Intertek Listed
shipQUICK models for AUTOM Series™ - Compact Low Energy Swing Door Operators
| AUTOM1V | Compact Single, Push Arm, 35mm Spindle, 23” Housing, 628 |
| AUTOM1Y | Compact Single, Push Arm, 35mm Spindle, 23” Housing, 335 |
| AUTOM2V | Compact Single, Pull Arm, 20mm Spindle, 23” Housing, 628 |
| AUTOM2Y | Compact Single, Pull Arm, 20mm Spindle, 23” Housing, 335 |
| AUTOM3V | Compact Single, Arm Kit, 35mm and 20mm Spindles, 23” Housing, 628 |
| AUTOM3Y | Compact Single, Arm Kit, 35mm and 20mm Spindles, 23” Housing, 335 |
